Step 20: Cafe Side Wall Assembly
Wood Parts
Hardware
A: Inbetweenboth(1931)PostsonCafeWallsideevenlyspaceandattach3(1503)CedarWallsoneachside
of(2031)RoofSupportto(2034)WallSupportand(2032)EndFloorusing4(S0)#8x7/8”TrussScrewsper
board.Thegapbetweenboardsshouldbeevenlyspacedat1”,notexceeding1-1/4”.Makesurethebottomof
theboardsaretightagainsttheoorboardsandbevellededgesarefacingoutandareatthetopoftheboards.
(g.20.1and20.2)
Note: Gaps between
boards evenly spaced at
1”, not to exceed 1-1/4”
Fig. 20.2
Note:Someboardswere
removedforclarity
Bevellededges
towardstopand
facingout
1503
1931
2031
1931
2034
1503
2032
S0
x24
1931
CafeWallSide
Fig. 20.1
24 x #8 x 7/8” Truss Screw
6 x Wall Board 1/2 x 4 x 20”
1503
S0
x3
x3
