Step 15: Attach Rock Wall to Fort
Note: Pre-drill all holes using a 1/8” drill bit before installing the wood screws.
Hardware
A:PlaceRockWallAssemblyfromStep2centredonandushtotopof(1908)FrontFloor(g.15.1and15.3).
Attach(0349)RockRailsto(1908)FrontFloorusing4(S15)#8x1-3/4”WoodScrewsasshowning.15.2.
B: Attach(1779)CEAccessBoardtotopofRockWallAssembly,ushtotopof(0349)RockRailsusing4(S2)#8
x1-1/2”WoodScrews.(g.15.4)
Flush
4 x #8 x 1-3/4” Wood Screw
4 x #8 x 1-1/2” Wood Screw
S15
Fig. 15.2
Fig. 15.1
Fig. 15.3
Front
Wood Parts
Fig. 15.4
1937
1 x CE Access Board 1 x 6 x 17”
1779
1908
S15
0349
S2
S2
1779
0349
0349
1908
