Step 23: Attach Canopy to Roof Frame
A:PlaceCanopyover(1900)Ridgemakingsurebottomedgesoftarpareevenonbothsidesofassembly.
(g.23.1and23.2)
B:SecureonesidebyattachingCanopyto1(1909)TarpFrontBackusing5(S5)#8x1/2”PanScrews(with
#8atwasher).(g.23.2)
C: MakesuretheCanopyistightandsmooththensecureoppositeendofCanopyto(1909)TarpFrontBack
using5(S5)#8x1/2”PanScrews(with#8atwasher).(g.23.2)
D: AttachCanopytoeachendof(1900)Ridgewith2(S5)#8x1/2”PanScrews(with#8atwasher).(g.23.2)
12 x #8 x 1/2” Pan Screw (with #8 at washer)
S5
Fig. 23.2
Fig. 23.1
1 x Canopy
1900
Canopy
S5
S5
x5perside
with#8atwasher
1909
Graphic Not Shown
