Note: Pre-drill all holes using a 1/8” drill bit before installing the lag screws.
B:Place(2034)WallSupportonboth(1931)Postsasshowning.9.3.
C:Place(2031)RoofSupportacrossthebottomof(2032)EndFloor,(2034)WallSupportand(2030)SideRoof
thenlooselyattachusing3(H2)1/4x2”HexBolts(withlockwasher,atwasherandt-nut)asshowning.9.3
and9.4.The(2031)RoofSupportshouldsit2-1/8”fromthetopof(2032)EndFloor.(g.9.4)
D:Makesureassemblyissquareandthenfasten(2032)EndFloorto(1931)Postsinthetopholesusing2
(LS1)1/4x1-1/2”LagScrews(withatwasher).(g.9.3and9.5)
E:Makesure(2034)WallSupportissquaretothepoststhenattachtoboth(1931)Postsusing4(S2)#8x
1-1/2”WoodScrews.(g.9.3and9.5)
F:Makesuretheassemblyissquarethentightenallboltsfromthisstep.Makesuretomaintain2-1/8”gap.
Fig. 9.3
Fig. 9.4
Step 9: Cafe Wall Assembly
Part 2
Fig. 9.5
Wood Parts
Hardware
3 x 1/4 x 2” Hex Bolt (1/4” lock washer, 1/4” at washer, 1/4” t-nut)
2 x 1/4 x 1-1/2” Lag Screw (1/4” at washer)
4 x #8 x 1-1/2” Wood Screw
1 x Wall Support 1 x 4 x 35-7/8”
1 x Roof Support 2 x 2 x 57-1/8”
2034
S2
2031
LS1
H2
1931
2032
LS1
LS1
S2
S2
H2
2034
2030
2031
1/4”Flat
Washer
1/4”Flat
Washer
1/4”Lock
Washer
1/4”
T-Nut
2-1/8”
2032
2031
1931
2032
2034
2030
2031
1931
