Step 10: Swing Wall Assembly
Part 2
Note: Pre-drill all holes using a 1/8” drill bit before installing the lag screws.
C:Place(2034)WallSupportonboth(1931)Postsasshowning.10.2.
D:Place(2035)SWMountacross(1895)FloorEnd,(2034)WallSupportand(2030)SideRoof.Looselyattach
using3(G4)5/16x4”HexBolts(withlockwasher,atwasherandt-nut)asshowning.10.2.
E:Makesureassemblyissquareandthenfasten(1895)FloorEndto(1931)Postsinthetopholesusing2
(LS1)1/4x1-1/2”LagScrews(withatwasher);and(0369)LowerDiagonalsto(1931)Postswith1(LS3)1/4x
3”LagScrew(withatwasher)perdiagonal.(g.10.2and10.3)
F:Makesure(2034)WallSupportissquaretothepoststhenattachtoboth(1931)Postsusing4(S2)#8x
1-1/2”WoodScrews.(g.10.3)
G:Tightenallbolts,exceptforthe(2035)SWMountbolts,fromthisstep.
Wood Parts Hardware
Fig. 10.2
Fig. 10.3
5/16”Flat
Washer
5/16”Lock
Washer
5/16”
T-Nut
1931
1895
2034
2030
2035
G4
LS3
1/4”Flat
Washer
0369
1931
1895
2034
S2
1/4”Flat
Washer
3 x 5/16 x 4” Hex Bolt (5/16” lock washer, 5/16” at washer, 5/16” t-nut)
2 x 1/4 x 1-1/2” Lag Screw (1/4” at washer)
2 x 1/4 x 3” Lag Screw (1/4” at washer)
4 x #8 x 1-1/2” Wood Screw
1 x Wall Support 1 x 4 x 35-7/8”
1 x SW Mount 2 x 4 x 59-1/2”
2034
S2
2035
LS1
G4
LS3
1931
LS1
