Selection
In addition to the weight and the usual weighing symbols, the display
shows one of the following symbols (see par. 4.1.1 on
page 1-30 ).
To set the range, press DRANGE , select the values with SELECT and
enter the numerical values using the number keys ( par. 4.3 on page
1-33 ).
WARNING
✔
The display range described here is independent of the
range associated with the outputs (see par. 5.2.8 on page
1-46 and par. 5.2.9 on page 1-46 .
Display tare
In addition to the usual weighing symbols, the terminal can also
simultaneously display the net weight and the tare (if present).
The following indications are displayed:
✔
If a tare has been entered by pressing and multiple tares
were not set during installation:
Tare: tare value + unit of measurement
The indications and PT will be illuminated.
✔
If the tare was acquired by pressing and multiple tares have
not been set:
Tare: tare value + unit of measurement
The indications and T will be illuminated.
If the tare is preset ( par. 5.2.13 on page 1-48 and multiple tares
have not been set:
Tare C: preset tare value + unit of measurement
The indications and PT will be illuminated.
✔
✔
D410
1-43
