C (E3) 08/2015 page 15/93
Figure 6: CO
2
incubator C 170, outer door open
(4) Glass door handle
(5) Water pan
(6) Shelves
(7) Shelf holder
(8) Pt 100 temperature sensor
(9) CO
2
sensor
(10) Gas mixing head for CO
2
(11) Silicone measuring port in the glass door
(11) (10) (9) (8) (7)
(1)
(4) (5) (6)
