C (E3) 08/2015 page 7/93
Prohibition signs
Do NOT touch
Do NOT spray with
water
Do NOT climb
Information to be observed in order to ensure optimum function of the product.
1.2.4 Word message panel structure
Type / cause of hazard.
Possible consequences.
∅ Instruction on how to avoid the hazard: prohibition
 Instruction on how to avoid the hazard: mandatory action
Observe all other notes and information not necessarily emphasized in the same way, in order to avoid
disruptions that could result in direct or indirect injury or property damage.
1.3 Localization / position of safety labels at the unit
The following labels are located on the unit:
Pictograms (Warning signs)
Service label
Hot surface
Risk of injury (UL units only).
Observe the safety instructions in the
operating manual.
Figure 1: Position of labels
on the CO
2
incubator C 170
Figure 2: Position of labels
on the CO
2
incubator C 170-UL
