C (E3) 08/2015 page 19/93
CAUTION
Danger of overheating.
Damage to the unit.
∅ Do NOT set up units in non-ventilated recesses.
Ensure sufficient ventilation for dispersal of the heat.
To completely separate the unit from the power supply, you must disconnect the power plug. Install the
unit in a way that the power plug is easily accessible and can be easily pulled in case of danger.
For the user there is no risk of temporary overvoltages in the sense of EN 61010-1:2010.
Do not install or operate the CO
2
incubator C 170 in potentially explosive areas.
DANGER
Explosion hazard.
Danger of death.
∅ Do NOT operate the unit in potentially explosive areas.
∅ KEEP explosive dust or air-solvent mixtures AWAY from the vicinity of the unit.
Ambient conditions
• Permissible ambient temperature range for operation: +18 °C / 64.4 °F up to +30 °C / 86 °F. At elevat-
ed ambient temperature values, fluctuations in temperature can occur.
• Ideal ambient temperature: by at least 7 °C / 12.6 °F below the intended working temperature. E.g.,
working temperature 37 °C / 98.6 °F – resulting permitted ambient temperature 30 °C / 86°F and lower
In the event of working temperatures of less than 7 °C / 12.6 °F above the ambient temperature, the set
point can be exceeded.
The ambient temperature should not be substantially higher than the indicated ambient tem-
perature of +22 °C +/- 3 °C / 71.6 °F ± 5.4 °F to which the specified technical data relate. For
other ambient conditions, deviations from the indicated data are possible.
Avoid direct solar radiation on the unit.
• Permissible ambient humidity: 70% r.H. max., non-condensing.
• Installation height: max. 2000 m / 6561.7 ft above sea level. After the incubator has been turned on for
the first time, enter the altitude of the site above sea level into the RP1 controller (chap. 8.1).
• Wall distances: rear 100 mm / 3.94 in, sides 50 mm / 1.97 in.
