Binder KBF 720 - Page 73

Repair work at the inner and outer chamber
Air
humidity
% r.H.
Meas-
ured
current
mA
Air
humidity
% r.H.
Meas-
ured
current
mA
Air
humidity
% r.H.
Meas-
ured
current
mA
Air
humidity
% r.H.
Meas-
ured
current
mA
Air
humidity
% r.H.
Meas-
ured
current
mA
0
4.00
20
7.20
40
10.40
60
13.60
80
16.80
1
4.16
21
7.36
41
10.56
61
13.76
81
16.96
2
4.32
22
7.52
42
10.72
62
13.92
82
17.12
3
4.48
23
7.68
43
10.88
63
14.08
83
17.28
4
4.64
24
7.84
44
11.04
64
14.24
84
17.44
5
4.80
25
8.00
45
11.20
65
14.40
85
17.60
6
4.96
26
8.16
46
11.36
66
14.56
86
17.76
7
5.12
27
8.32
47
11.52
67
14.72
87
17.92
8
5.28
28
8.48
48
11.68
68
14.88
88
18.08
9
5.44
29
8.64
49
11.84
69
15.04
89
18.24
10
5.60
30
8.80
50
12.00
70
15.20
90
18.40
11
5.76
31
8.96
51
12.16
71
15.36
91
18.56
12
5.92
32
9.12
52
12.32
72
15.52
92
18.72
13
6.08
33
9.28
53
12.48
73
15.68
93
18.88
14
6.24
34
9.44
54
12.64
74
15.84
94
19.04
15
6.40
35
9.60
55
12.80
75
16.00
95
19.20
16
6.56
36
9.76
56
12.96
76
16.16
96
19.36
17
6.72
37
9.92
57
13.12
77
16.32
97
19.52
18
6.88
38
10.08
58
13.28
78
16.48
98
19.68
19
7.04
39
10.24
59
13.44
79
16.64
99
19.84
20
7.20
40
10.40
60
13.60
80
16.80
100
20.00
Table 3: Current and humidity values of the humidity sensor
