Repair work at the humidifying and dehumidifying system
1
• Steam hose (tissue), 1200 mm / 47.24 in
2 • Pressure hose with metal braiding
3
• Reflux valve
4
• Water pump for steam boiler (-9M10)
5
• Valve block pressure controller complete
- Valve block with safety valve
- Manometric switch with relay (-9F30)
- Solenoid valve steam outlet (-9Y10)
- Screw nut for valve block
- Squeezing ring for valve block
6
• Pressure compensation hose to outlet tank, 730 mm / 28.47 in
7
• Pressure compensation hose to outlet tank, 720 mm / 28.35 in
8
• Suction hose for water pump (-9M10), 800 mm / 31.49 in (freshwater)
9
• Control board humidification module (-9N10)
10
• Pilot lamp, red 230 V
11
• Evacuation pump 200 - 240V, 50 / 60 Hz (-8M1)
12
• Power contactor (-9K10)
13
• Freshwater inlet hose: Water hose ½", length: 450 mm
• Hose clamp 12-20 mm / 0.47 x 0.79
14 • Tank connection
15
• Tipping float switch (-10S2)
16
• Float switch (filling level and overflow sensor) (-10S1)
17
• Square tank, outlet
18 • Square lid, outlet
19
• Diode (max. 240 VDC), (-10V2)
20
• Condensate outlet hose ½" outer chamber
KBF 115: 1360 mm / 53.54 in
KBF 240: 1450 mm / 57.09 in
KBF 720: 1650 mm / 6496 in
• Hose clamp 20-32 mm / 0.79 x 1.26 in
21
• Air relief hose of reflux valve, 700 mm (freshwater)
22 • Square tank, inlet
23
• Square lid, inlet
24 • Cable nozzle D10 mm
25
• Tank fixing sheet
26 • Hose holder fix ½"
27
• Tipping float switch (-10S3))
28
• Solenoid valve 24 V, 0.2 - 10 bar, freshwater inlet valve (-10Y1)
