Repair work at the humidifying and dehumidifying system
c
• Freshwater connection
d • Waste water connection
29
• Waste-water hose evacuation pump:
Silicon hose, transparent Ø 20, length: 130 mm
• Hose clamp 20-32 mm / 0.79 x 1.26 in
30
• Boiler insulation complete
- Boiler insulation upper part
- Boiler insulation bottom part
31
a
e
b
• Steam boiler complete (-9A10)
- Steam boiler
- Boiler sensor
- Power contactor (-9K10), (order no. 5011-0007)
- Diode 6 A/600 V (-9V10), (order no. 5022-0001)
- Double manometric switch 2 -6 bar (-9F30), (order no. 5006-0078)
- Temperature fuse 160°C / 320°F (-9F20) automatic
- Temperature fuse 175°C / 347°F (-9F10)
- Filling level electrode
32 • Heating steam boiler
33
• Insulating disk M 16
34 • Boiler fixing nut M 16
35
• Seal ring for discharging screw
36 • Discharging screw
Danger of electric shock.
Danger to life.
The humidification module is supplied with electrical tension event if the humidity switch
is switched off.
Any service tasks at the humidification module must only be performed if the KBF is
disconnected from the power supply.
Disconnect the unit from the power supply, prior to performing repairs at the humidifi-
cation module.
Danger by hot water.
Danger of scalding.
Prior to start working, make sure that the unit has cooled down.
