KBF-S / KBF-S-UL (E6) 11/2021 page 19/95
2.1 Chamber overview
Figure 5: Constant climate chamber KBF-S / KBF-S-UL size 240
(1) Main power switch
(2) Instrument panel with RD4 chamber controller and USB interface
(3) USB interfaces
(4) Door handle
(5) Chamber door
(6) Location of Peltier modules and humidity generation system
(2)
(3)
(4)
(5)
(6)
(1)
