2.2 Rear chamber view
(10)
(11)
(12) (9)
(7)
(8)
(9)
Figure 6: Rear view of the chamber (example: KBF-S / KBF-S-UL 240)
(7) Freshwater can with can support
(8) Hose leading to the freshwater can
(9) Hose fixing devices
(10) Ethernet interface
(11) Power cable
(12) Condensate collection pan
