KBF-S / KBF-S-UL (E6) 11/2021 page 8/95
1.4.4 Word message panel structure
Type / cause of hazard.
Possible consequences.
∅ Instruction how to avoid the hazard: prohibition
 Instruction how to avoid the hazard: mandatory action.
Observe all other notes and information not necessarily emphasized in the same way, in order to avoid
disruptions that could result in direct or indirect injury or property damage.
1.5 Localization / position of safety labels on the chamber
The following labels are located on the chamber:
Pictograms (warning signs)
Risk of injury (on chamber door, only KBF-S-UL).
Observe the safety instructions in the operating manual.
Observe the prescribed freshwater quality
(on the freshwater can)
Burning and scalding hazard (chamber rear)
Service label
Figure 1: Position of labels on the chamber front
(KBF-S-UL)
Figure 2: Position of label on the chamber rear
