BIRD FlightHawk - Physical and Environmental Specifications; Termination Specifications

FlightHawk RF Test Set
88
Physical and Environmental Specifications
Termination Specifications
Temp, Operating –10 to +50 °C (+14 to +122 °F)
Temp, Storage –40 to +80 °C (–40 to +176 °F)
Mechanical Shock and
Vibration
MIL-PRF-28800F class 3
Humidity, Max 95% (non-condensing)
Altitude, Max 15,000 ft. (4,500 m)
Dimensions, Nominal 4.75” x 4.6” x 1.3” (121 x 117 x 33 mm)
Weight, Max 1.2 lb. (0.55 kg)
EMC
EMC Directive (2004/108/EC)
European Standard: EN 61326—
Electrical Equipment for measurement,
control and laboratory use; EMC
Requirements
Test Spec (for radiated immunity): EN
61000-4-3—Testing and measurement
techniques - 10V/meter
Frequency Range DC- 4 GHz
RF Power Range
25 W max at 40° C
30 W max at 25° C
Impedance, Nominal 50 ohms
Input VSWR, Max
DC – 1 GHz
1 GHz – 4 GHz
1.10:1
1.25:1
RF Connector N male
Coolant Air, Convection Cooled
Dimensions 4.7” long x 2.3” diameter
Weight 7 oz.
