FlightHawk-AV Basic Operation
11
Velocity
1. Select Velocity.
2. Set speed value.
Note: Manually enter cable velocity value or select the cable type
from the cable list.
Cable Loss
1. Select CableLoss.
2. Set cable loss values.
Note:
• Manually enter cable loss value or select the cable type from the cable
list.
• If manually entering the CableLoss (or Attenuation value), it must be
entered in dB/ft, or dB/meter. The manufacturer generally gives these
values as dB/100ft or dB/100meters.
Cable List
The Cable List contains known cable values for a variety of cable types. The
Cable List may be edited to add or delete cables.
"Edit Cable List" on page 75 .
1. Select CableList.
2. Set cable type.
3. Select a certain cable type.
Note: Each cable type in the cable list has the fixed values for cable
velocity and cable loss. Selecting a cable from the cable list will
automatically populate the cable velocity and cable loss data fields.
