Specifications
85
5017D-AV Specifications
Average RF Power
Frequency Range
5017D–AV 100 MHz to 1.3 GHz
RF Power Range
500 mW to 500 W average,
13.3W to 1300 W peak
1
1 Derate maximum average power rating from 500W at 300MHz to
100W at 1GHz using a straight line on a log-log scale.
Maximum Power See
Figure 75 on page 87
.
Impedance, Nominal 50 ohms
Insertion Loss, Max:
100 – 1000 MHz
1000 – 1300 MHz
0.05 dB
0.1 dB
Input VSWR, Max:
100 – 1300 MHz 1.05
Directivity, Min:
100 – 1300 MHz 30 dB
RF Connectors N Female
Interface:
DPM
PC Serial Port
PC USB Port
Male DB-9, RS-232, 9600 Baud, no parity,
8 data bits, 1 stop bit
Female DB-9, EIA-232, 9600 Baud, no
parity, 8 data bits, 1 stop bit
USB 1.1 interface
Power Supply:
DPM
USB Port
DC Connector
From host instrument via cable
less than one low-power USB load
7 – 18 Vdc, < 100 mA
Data Logging In VPM/Bird Power Meter software
RF Power Range
1
1 Derate maximum average power rating from 500W at
300MHz to 100W at 1GHz using a straight line on a log-log
scale.
500 mW – 500 W
Peak/Average Ratio, Max 12 dB
Measurement Uncert.
± (4% of reading + 166 mW)
2
2 Above 35 °C or below 15 °C add 3%
