Introduction
3
FlightHawk-AV Analyzer
The FlightHawk-AV is a multifunction test instrument for use in installation and
maintenance of RF communications systems.
The unit has a frequency range of 1 MHz to 6 GHz. Additional FlightHawk-AV
specifications can be found in the specifications chapter, See
"Specifications"
on page 82
.
Antenna systems are tested by using a FlightHawk-AV Analyzer to measure
match (VSWR) and distance -to-fault conditions. Data points measured across a
user-specified frequency band or distance range are graphed on a 1280 x 720
pixel touch screen display area.
TNC Female 4240-407
UHF Male 4240-408
UHF Female 4240-409
SMA Male 4240-410
SMA Female 4240-411
Couplers (5) 4240-413
Hard Carrying Case FH-AV-CC
USB Cable, 10 ft. 5A2653-10
USB Adapter SK-CONN-OTG-2
USB Drive 5A2745-1
AC Adapter (12VDC) SK05T-1200300Z
Touch Pen (stylus) SK-TP-112
USB Drive 5A2745-1
Calibration Combination (Cal Combo), DC - 6 GHz SK-CAL-MN-C6
Operation Manual
1
920-7003A001-4
Virtual Power Meter 3
2
VPM3
1 Operation manuals are supplied digitally on a CD and USB drive in PDF
format.
2 VPM3 is Power Meter software for Windows OS which may be used in
conjunction with Bird Power Sensors to display RF power measurements
in real time on a PC. The VPM3 installation software is supplied on a CD
and USB drive.
