FlightHawk RF Test Set
6
Table 1 User Interface Description Explanation
Note: When a fault Detection mode is selected, Start, Stop, and
DTFMax fields are also displayed below the sweep display area.
Item Description
1 Current Date and Time, latitude and longitude.
Note: Location services must be set to On for the
FlightHawk-AV to display latitude and longitude
data. See
"Accessing Communication Services"
on page 47
.
2 Measurement Mode, press to display Measurement Mode
menu.
3 Trace Selection, press to choose number of traces to display.
4 Pause icon, when pressed pauses data acquisition.
When data acquisition is paused a play icon is displayed.
5 MKR icon, press to display the Marker menu.
6 SCALE icon, press to display the scale menu.
7 LIMIT icon, press to display the limit menu.
8 DTF icon, press to display the Distance to Fault menu.
9 CAL icon, press to display the calibration menu.
10 Menu icon, press to display additional utility menus: MEM,
FREQ, RESET, FILE, PNG, SYS.
11 Battery charge remaining in time, percentage, and visual
indicator.
12 Stop Frequency, press the data field to change the value, or
press the label to change to frequency Span (16).
13 Sweep display area.
14 Points, press the data field to choose the number of
measurement points.
15 Start Frequency, press the data field to change the value, or
press the label to change to Center Frequency (17).
16 Span displays the current frequency span. Press the data
field to change the value, or press the label to change to
Stop Frequency (12).
17 Center Frequency, press the data field to change the value,
or press the label to change to Start Frequency (15).
