CHAPTER 2: OVERVIEW
2.1 INTRODUCTION
The Industrial Managed and Unmanaged Gigabit Ethernet Switches include unmanaged switches that provide four
(4) copper RJ-45 or RJ-45 PoE ports and one (1) multi-rate SFP slot and managed switches that provide six (6), eight (8) or ten (10)
copper RJ-45 or RJ-45 PoE ports and two (2) or four (4) multi-rate SFP slots.
Power over Ethernet
The LIE401A, LIE1014A, LIE1080A and LIE1082A switches support Power over Ethernet compliant to the IEEE 802.3af and IEEE
802.3at standard on all copper ports. Thus these switches can be used to power standard PoE PD devices with up to 30 watts per
port along with the Ethernet data on standard Ethernet Cabling.
Multi-rate SFP slots
The benefit of having multi-rate SFP slots is to be able to use 100-Mbps and 1-Gbps SFP Modules for either multi- or single-mode
in a mix and match as needed. If requirements change, just replace the SFP module and protect your switch investment.
Power
The switches are powered from 12- to 58-VDC. The PoE models need 48 VDC for 802.3af and a minimum of 53 VDC for 802.3at.
Extended temperature range
All models are tested and released for operating temperatures from -40° up to +75° Celsius. They passed shock, vibration and
freefall test and comply with the IEC600068-2-6, -27 and -32 standards.
Management
The switches offer powerful features including Layer 3 routing and management with all advanced filter and multicast
algorithms needed today to easily prioritize, partition, and organize a reliable high-speed network.
2.2 AVAILABLE MODELS
Six models of the Industrial Gigabit Ethernet Switches are available:
 Industrial Gigabit Ethernet Switch - Managed, Extreme Temperature, (10) RJ-45, (4) SFP (LIG1014A)
 Industrial Gigabit Ethernet Managed L2+ Switch - Extreme Temperature, (8) RJ-45 (LIG1080A)
 Industrial Gigabit Ethernet Managed L2+ Switch - Extreme Temperature, (6) RJ-45, (2) SFP (LIG1082A)
 Industrial Gigabit Ethernet PoE+ Switch - Managed, (8) RJ-45, (4) SFP (LIE1014A)
 Industrial Gigabit Ethernet Managed L2+ Switch - PoE+, Extreme Temperature, (8) RJ-45 (LIE1080A)
 Industrial Gigabit Ethernet Managed L2+ Switch - PoE+, Extreme Temperature, (6) RJ-45, (2) SFP (LIE1082A)
SPECIFICATION COMPARISON CHART
LIE1014A LIE1080A LIE1082A LIG1014A LIG1080A LIG1082A
RJ-45 POE PORTS 8 8 6 — — —
RJ-45 PORTS — — — 10 8 6
SFP PORTS 4 NONE 2 4 NONE 2
P1 LED 1 NONE 1 1 NONE 2
P2 LED 1 1 1 1 1 1
ALM LED 1 1 1 1 1 1
ETHERNET PORT LINK LED 8 8 6 10 8 6
ETHERNET PORT SPEED LED 8 8 6 10 8 6
SFP PORT LINK LED 4 NONE 2 4 NONE 2
SFP PORT SPEED LED 4 NONE 2 4 NONE 2
MANAGED YES YES YES YES YES YES
