CHAPTER 1: SPECIFICATIONS
1.4 LIE1014A
INDUSTRIAL MANAGED POE GIGABIT ETHERNET SWITCH (LIE1014A)
APPROVALS
STANDARDS UL508/CSA C22, EN61010-1, CE, FCC Part 15, CISPR22 (EN55022) Class A, IEC60068-2-6, -27, -32 (Vibration, Shock, Free Fall),
MTBF > 25 years, IEC61000-4-2, -3, -4, -5, -6 (Level 3)
FEATURES Web, SNMP v1/v2c, Telnet, HTTPS, SSH, Radius, TFTP/FTP, Syslog, VLAN, Diagnostic Tools, RMON 1,2,3,9, DHCP,
Client/Server/Snooping/Relay/Option82, QoS, IGMP Proxy/Snooping v1/v2, Filter Features, LLDP, STP, RSTP, MSTP, LACP
FIRMWARE
MAC ADDRESS 8000 MAC Addresses
FRAME SIZE 9000 Bytes (Jumbo frame capable)
BUFFER MEMORY 512 kbytes
HARDWARE
CHASSIS IP30
CONNECTORS (8) RJ-45, IEEE 802.3at PoE PSE ports, 10/100/1000 Mbps speed auto-negotiation, MDI-MDI-X auto-crossover;
(4) 100/1000BASE-SFP module slot, (1) RJ-45 console port
INDICATORS (1) P1 LED, (1) P2 LED, (1) ALM LED, (8) RJ-45 Ehernet Port Link LEDs, (8) RJ-45 Ethernet Port Speed LEDs, (4) SFP Port Link LEDs, (4)
SFP Port Speed LEDs, (8) PoE Port LEDs
DIMENSIONS (WITHOUT DIN
RAIL CLIP)
6.1”H x 3.0”W x 5.0”D (15.4 x 7.7 x 12.8 cm)
WEIGHT 3.1 lb. (1.4 kg)
INSTALLATION OPTIONS DIN-rail mounting;
Wallmounting
POWER
POE Yes
INPUT Redundant input terminals, reverse power protection, 12 –58 VDC, 54–58 VDC for PoE+, 48–58 VDC for PoE
MAXIMUM POWER Without PoE: 14 Watts,
With PoE: 265 Watts
ENVIRONMENTAL
OPERATING TEMPERATURE -40 to +167° F (-40 to +75° C), cold startup at -40° C
STORAGE TEMPERATURE -40 to +185° F (-40 to +85° C)
HUMIDITY 5 to 95% RH (non-condensing)
