CHAPTER 3: INSTALLATION
MANAGED SERIES
PWR1
CONSOLE
RESET
+ – – +
+
ALM PWR2
SECOND POWER SUPPLY
FIRST POWER SUPPLY
FIGURE 3-7. MANAGED SERIES
POE MANAGED SERIES
PWR1
CONSOLE
RESET
+ – – +
+
ALM PWR2
FIRST POWER SUPPLY
SECOND POWER SUPPLY
FIGURE 3-8. POE MANAGED SERIES
