EP600 Energy Storage System User Manual
57
Figure 6-10 CT Interface
There are two methods to obtain grid-connected current information and prevent backflow when needed:
Table 6-9
Method A
CT
Figure 6-11
Method B
Electricity Meter + CT
Figure 6-12
Description
The system with each phase current less than 100A can directly connect to CT
or electricity meter; if the current exceeds 100A, only the meter can be used.
Pay attention to the direction,
the direction of the arrow
towards the grid.
GRID-L1
GRID-L2
GRID-L3
