EP600 Energy Storage System User Manual
56
Step2: Thread the extension cable into the connector shell and install the corresponding signal cable
into the connector pins.
Step3: Tighten the screws of the connector with a screwdriver.
Step4: Gently pull the connection cable of 6 pins to determine whether the connection is tight;
Step5：Tighten the connector shell and nut clockwise.
lock the
screws
connector housing
CT connect cable Signal extension cable
