Figure 6-9 COM interface
6.8.5 CT-current transformer interface
Table 6-8
PIN
Define
Function
Rem
ark
1
CT-R-(Black)
Negative pole of current
transformer Output
For Connecting to current transformer
of grid R phase
2
CT-R+(Red)
Positive pole of current
transformer Output
3
CT-S-(Black)
Negative pole of current
transformer Output
For Connecting to current transformer
of grid S phase
4
CT-S+(Red)
Positive pole of current
transformer Output
5
CT-T-(Black)
Negative pole of current
transformer Output
For Connecting to current transformer
of grid T phase
6
CT-T+(Red)
Positive pole of current
transformer Output
Operation steps.
Step1: Remove the unconnected end of the CT connector adapter counterclockwise.
