Dokumentace stroje Dokumentation der Maschine
Machine documentation
Remove the nut from the handle of the hand wheel, place it into the hex opening
on the back side of the wheel and fasten the handle.
2.5.6. Machine installing and leveling
Check the floor supporting capacity before installing the machine. If the floor
capacity does not meet the requirements, you must ready the necessary base for
the machine.
Minimal requirement:
machine weight – Ergonomic 340.278 DGH – 410 kg
+ weight of the accessories
+ maximum weight of material
 The machine must be leveled in a horizontal position. All feet of the machine
must touch the floor after leveling.
 The machine must be leveled by means of a calibrated spirit level. Put the spirit
level near the vice. Adjust the roller conveyors according to the spirit level.
 For machine leveling, take care that there is sufficient space available for
operation, repair work, servicing of the machine and handling of the material.
 The machine and all appended parts and accessories must be visible from the
place of operation.
2.5.7. Putting into operation of the hydraulic unit
Before the first run check:
 the tank is filled with the prescribed oil to upper limit
 pump is not running in the opposite direction. Hydraulic generator must not
be operated in opposite directions of rotation for longer than 5-10 seconds.
 connections are properly tightened, pipes assembled without internal stress
 wiring matches with electrical and hydraulic diagrams
 the electric motors (pump and cooler) are properly connected and have the
prescribed rotation
 the hydraulic accumulator with nitrogen gas to the specified value
 aux. elements work right (thermometer, level gauge, heater)
First run (Attention – working pressure on securing valve is set by producer in
accoring the hydraulic diagram):
 In the short intervals activate an electric pump
 check for leaks and noise
 Bleed the hydraulic circuit
 if possible, test the circuit function with minimum load
 test the electrical equipment
 during operation monitor measuring equipment, noise, height and
temperature of oil in the tank
 During this time a careful bleeding off for the whole hydraulic system is
necessary. In case there is no bleeder port, the power pack will bleed itself
after a while via the air breather on the tank or the return line filter.
