79
Údržba stroje
Wartung
1. Tighten the screw on the side of guide cube so that the band is loosened
2. Loosen the screw slowly and let the hard metal plate touch the band. You
must be able to turn the screw by hand. Set the hard metal guiding on
the right cube in the same way.
3. Make sure that the hard metal guides do not put up to much resistance
otherwise the lifetime of the saw band and drive decreases.
4.4.3. Guide cube adjustment
Cutting quality and saw band life is also dependent on guide cubes adjustment
Therefore this adjustment has to be checked periodically
15. Loosen both mounting screws on the guide cubes and push it carefully to the
band. Make sure the saw band is not bent; otherwise the cube will press
against the band and damage it
16. Fasten both tightening screws again
Notice:
If the guide cube is correctly adjusted, the upper edge of
the cube and the ruler are parallel.
