99
Údržba stroje
Wartung
4.9. Worn pieces replacement
4.9.1. Hard metal guides replacement
If the hard metal guides cannot be adjusted, they have to be replaced.
5. Remove the hosepipe leading to the cooling agent and dismantle saw band
and saw band guiding cube.
6. Fasten the guiding cube to the vice and screw out the screws of both the hard
metal desks.
7. Screw out the adjusting screw of the adjustable guiding desk as far from the
guide cube so that it is not possible to see it from the inner side.
8. Now insert new hard metal guides and fasten them tightly and fasten the
guide cube to the gib.
9. Install the saw band and adjust guide cube and hard metal guides.
Attention!
Vice must has aluminum jaws or should be placed in a vice
aluminum produc, that avoid damage to the pin during
clamping.
