Bomar Ergonomic Series User Manual

78
Manual version: 1.01/ Febr. 2017
Manual rev.: 1
Údržba stroje
Wartung /
Machine service
 If the distance is bigger than 1 mm, or the saw band runs on the rim of the
wheel, adjust the saw band.
14. Close cover of the saw band.
4.4. Adjustment
4.4.1. Saw band run adjustment
The saw band run is set with screw in the stretching cube on the saw frame.
Optimal distance has been determined at 1mm
 Turn the screw to the right, the saw band closes to the stretching wheel
rim
 Turn by screw to the left, the saw band departs from the stretching wheel
rim
After setting check the saw band run again.
4.4.2. Hard metal guides adjustment on the machine
Hard metal guides adjustment is one of the most important criterions which
influence cutting accuracy and saw band lifespan. Therefore it is essential to check
that the adjustment of the hard metal guides is correct
