General Information Regarding BUEP-E and BUEP19E
7--7
1070 072 196-101 (00.06) GB
Address PST High Part
Parameter
Word
Contents
PW10 Address PST high part
Example F0
H
ZS400
In this parameter, the block address of the module to which the PST com-
mand is referred, is specified.
Address PST Low Part
Parameter
Word
Contents
PW11 Address PST low part
Example 46
H
70 bytes
In the low part of the PST address, the byte address (offset) of the used com-
mand is specified.
Amount of Data
Parameter
Word
Contents
PW12 Amount of data (in data types) according to type of operand
Example 28
H
Amount = 40
In this parameter, it is specified how much data -- in relation to the operand
type -- has to be transferred.
If the operand type ’mask’ is used, the amount of data must be set to 1. Then,
the double length (setting mask and resetting mask) of the type that is speci-
fied in the mask identifier (e.g. the word mask) is always transmitted in the
following order: low part, high part.
Example:
Parameter
Word
PW11 Number in Bytes
Byte 3 3
Word 7 14
Double word 2 8
Quad word 5 40
Byte mask 1 2
Word mask 1 4
Double word
mask
1 8
Quad word
mask
1 16
