When ready, return to the original calendar and channel setup interface by
clicking
7 Smart
search
This function is only active when the system is playing a recording in 1-
window mode.
Click to activate smart search. See following figure.
Use your mouse to drag and select zone(s) in the window to detect motion.
Click
again to begin smart search.
The system searches for motion in the chosen area(s).
When ready, click again to stop smart search playback.
Extra notes on smart search:
– As default, the system will view the whole play zone as a motion detect
region.
– If you choose to play another file in the file list, the system will switch
to motion detect play of the other file.
– During motion detect play, you cannot implement operations such as
changing the time bar, play backward, or play frame-by-frame.
– System supports 396 (22x18 PAL) and 330 (22x15 NTSC) zones.
100
en | Operating instructions DIVAR AN 3000 / DIVAR AN 5000
2014.10 | 2.0 | AM18-Q0669 Operations Manual Bosch Security Systems

Bosch DIVAR AN 5000 Specifications

General

Motion sensor	Yes
Total storage capacity	2000 GB
Video compression formats	H.264
Analog signal format system	NTSC, PAL
Compatible operating systems	Windows XP, Windows Vista, Windows 7.
Playback resolutions supported	960x576, 960x480, 704x576, 704x480, 704x288, 704x240, 352x288, 352x240, 176x144, 176x120
Audio input	4
BNC input ports	16
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
HDD interface	Serial ATA
Maximum HDD capacity	3000 GB
Power requirements	100-240VAC 50-60Hz
Optical drive included	No
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 93 %

Weight and Dimensions

Dimensions (WxDxH)	440 x 420 x 70 mm
