Bosch DIVAR AN 5000 User Manual

5.6 RS485 port connection 31
5.7 RS232 port connections 31
5.8 USB connectors 32
5.9 e-SATA connector (only DIVAR AN 5000) 32
5.10 Alarm I/O connections 33
5.10.1 Connecting the alarm input 33
5.10.2 Connecting the alarm output 34
5.11 Power supply 34
6
Configuration 35
6.1 Setting 36
6.2 General 37
6.3 Encode 39
6.3.1 Overlay 40
6.3.2 Snapshot 41
6.3.3 Copy 41
6.4 Schedule 43
6.5 Serial port 45
6.6 Network 47
6.6.1 Network settings 49
6.6.2 IP filter 50
6.6.3 NTP 51
6.6.4 PPPoE 51
6.6.5 DDNS 52
6.6.6 UPnP 53
6.6.7 EMail 54
6.6.8 FTP server 55
6.6.9 SNMP 56
6.7 Alarm 57
6.8 Detect 59
6.8.1 Motion detect region setup 61
6.8.2 Period 62
6.8.3 PTZ activation 63
6.9 Pan/Tilt/Zoom 64
6.10 Display 65
6.10.1 Sequence Mon. A 66
6.10.2 Playback Disclaimer 67
6.11 Default 68
6.12 Advanced 69
6.13 Hard Disk (HDD) 70
6.14 System events 71
6.15 Alarm Output 72
6.16 Record 73
6.17 Account/Users 74
6.17.1 Add user 75
6.17.2 Modify/Delete a user 76
6.17.3 Modify password 77
6.18 Auto maintain 78
6.19 MON adjust 79
6.20 Text data overlay 80
4 en | Table of Contents DIVAR AN 3000 / DIVAR AN 5000
2014.10 | 2.0 | AM18-Q0669 Operations Manual Bosch Security Systems

Bosch DIVAR AN 5000 Specifications

General

Motion sensor	Yes
Total storage capacity	2000 GB
Video compression formats	H.264
Analog signal format system	NTSC, PAL
Compatible operating systems	Windows XP, Windows Vista, Windows 7.
Playback resolutions supported	960x576, 960x480, 704x576, 704x480, 704x288, 704x240, 352x288, 352x240, 176x144, 176x120
Audio input	4
BNC input ports	16
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
HDD interface	Serial ATA
Maximum HDD capacity	3000 GB
Power requirements	100-240VAC 50-60Hz
Optical drive included	No
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 93 %

Weight and Dimensions

Dimensions (WxDxH)	440 x 420 x 70 mm
