PART III: PANEL PROGRAMMING
49.0 Reporting Format Configuration
49.1 Personal Dialing Format Configuration
• Address: See table below
• Default: See table below
• Selections: 0-15
Address
Personal Dialing
Format Code
Default Address
Personal Dialing
Format Code
Default
3414 Duress 3 3422 RF Trouble 7
3415 Fire Alarm 1 3423 Open/Close 0
3416 Non-fire Alarm 2 3424 Installer Mode 0
3417 Reserved 0 3425 System Fault 8
3418 Fire Trouble 5 3426 Test Report 0
3419 Non-fire Trouble 6 3427 Reserved 0
3420 Fire Restoral 0 3428 Bypass 0
3421 Non-fire Restoral 0 3429 Output/User 0
49.1.1 Parameter Description
Use this parameter to select the tone for the 16 different Personal Dialing Format event groups.
For each event group, the report is programmed as a value from 0 to 15. If 0 (zero) is programmed, no report is sent and the
event is a Local Only event. If the value is non-zero (1-15), the two-digit report tone sent is selected using the following table:
Data Digt Selection Report Tone Data Digt Selection Report Tone
0 None 8 2 2
1 1 0 9 3 1
2 1 1 10 4 0
3 2 0 11 1 4
4 1 2 12 2 3
5 2 1 13 3 2
6 3 0 14 4 1
7 1 3 15 5 0
For example, if Data Digit Selection “5” is entered, the following report tone is transmitted (“-“ equals 1 beep): -- -. There is a
1-second pause between the transmission of the first digit and the second digit. The second digit is followed by a 3-second
pause. The panel repeats the report for a total of ten times.
Address 3414 holds the tone for Event Group 1; Address 3429 holds the tone for Event Group 16. To change an event group’s
report tone, enter the data digit selection number from the table above into the appropriate programming address.
See Section 55.0 Personal Dialing Format on page 145 for more information.
