Appendix C
Table 11: continued
Point-Related Events
Report
Description
SIA
Code
SIA
Description
Contact ID
Code
Contact ID
Description
4/2 Code
Default
Values
Modem IIIa
2
Description
Phone 2 Trouble LT 2
Phone Line
Trouble
1 352 aa 000 Telco 2 Fault FC
Phone Line Fail
Phone Line = 2
Phone 2 Restore LR 2
Phone Line
Restoral
3 352 aa 000 Telco 2 Fault EC
Phone Line Restoral
Phone Line = 2
System Trouble IA
Equipment Failure
Condition
1 300 aa 000 System Trouble FD Equipment Fail
System Trouble
Restore
IR
Equipment Fail
Restoral
3 300 aa 000 System Trouble ED Equipment Restoral
Fire Drill Start FI Fire Test Begin 1 607 00 000
Walk Test
Mode
F2
Fire Walk Start
ID: 0000
Fire Drill End FK Fire Test End 3 607 00 000
Walk Test
Mode Restore
E2
Fire Walk End
ID: 0000
System Test TS Test Start 1 607 aa 000
Walk Test
Mode
26 Walk Test Start
System Test
Restore
TE Test End 3 607 aa 000
Walk Test
Mode Restore
27 Walk Test End
Silence KB Heat/Bypass 1 607 aa 000 Open/Close 1F Alarm Silence
Manual Test RX Manual Test 1 601 aa 000
Manual Trigger
Test
FE
Test Report Non
Expanded
Data Lost RT Data Lost 1 354 aa 000
Fail to
Communicate
FF
Communications
Fail *
EEPROM Failure IA 4
Equipment Failure
Condition
1 307 aa 000
Self Test
Failure
FD
Parameter Checksum
Fail
Trouble Input IA 2
Equipment Failure
Condition
1 300 aa 002 System Trouble FD
Equipment Fail
COND = 002
Trouble Input
Restore
IR 2
Equipment Fail
Restoral
3 300 aa 002 System Trouble ED
Equipment Restoral
COND = 002
System Trouble
Keypad
IA 5
Equipment Failure
Condition
1 300 aa 005 System Trouble FD
Equipment Fail Cond
= 005
System Restore
Keypad
IR 5
Equipment Fail -
Restoral
3 300 aa 005 System Trouble ED
Equipment Restoral
Cond = 005
System Trouble
Comm Fault
IA 6
Equipment Failure
Condition
1 300 aa 006 System Trouble FD
Equipment Fail Cond
= 006
System Restore
Comm Fault
IR 6
Equipment Fail
Restoral
3 300 aa 006 System Trouble ED
Equipment Restoral
Cond = 006
System Trouble
Programming
IA 11
Equipment Failure
Condition
1 300 aa 011 System Trouble FD
Equipment Fail Cond
= 011
System Restore
Programming
IR 11
Equipment Fail
Restoral
3 300 aa 011 System Trouble ED
Equipment Restoral
Cond = 011
Serial
Communication
Fault
YC
Communications
Fail
1 350 aa 000
Communication
Trouble
FD
Comm Fail,
RG = 1
Serial
Communication
Restore
YK
Communications
Restoral
6 350 aa 000
Communication
Trouble
Restoral
ED
Comm Fail
Restr = RG1
Refer to Notes 1 through 9 on page 52.
* In Modem IIIa2, the FPT-DACT uses Communications Fail to report a Data Lost event. The FPT-DACT reports an Equipment Fail
and Equipment Fail Restore with Condition 006 to report an actual Communications Fault.
