EN | 55FPT-DACT | Operation & Installation Guide |
1/05 | F01U002505B
Appendix E
Appendix E: Report Routing
The information in Appendix E shows the mapping of
point-related and non-point-related events to their
respective report routing group, lists the priority level
of each event, and identifies the reporting limit for
specific types of events.
Table 13: Point-Related Report Routing
Point-Related Events
Report
Description
Report Routing Report Priority
Point Fire Alarm NONSUP ALRM 0
Point Waterflow
Alarm
NONSUP ALRM 0
Point Supervisory
Alarm
SUPVSY ALRM 3
Point Monitor
Alarm
NONSUP ALRM 3
Point Fire Trouble* TBL, TBL RSTR 3
Point Waterflow
Trouble*
TBL, TBL RSTR 3
Point Supervisory
Trouble*
TBL, TBL RSTR 3
Point Monitor* TBL, TBL RSTR 3
Point Fire Dirty
Report*
TBL, TBL RSTR 3
Pont Fire Disable* TBL, TBL RSTR 3
Point Fire Alarm
Restore
ALM RSTR, RST 4
Point Waterflow
Restore
ALM RSTR, RST 4
Point Supervisory
Restore
SUPVSY RSTR 4
Point Monitor
Restore
SUPVSY RSTR 4
Point Fire Trouble
Restore*
TBL, TBL RSTR 4
Point Waterflow
Trouble Restore*
TBL, TBL RSTR 4
Point Supervisory
Trouble Restore*
TBL, TBL RSTR 4
Point Monitor
Trouble Restore*
TBL, TBL RSTR 4
* Event is limited to a total of 100 reports sent in a 24-h
period. If this limit is exceeded, the 100
th
event is replaced
with a Data Lost Report.
Table 14: Non-Point Related Report Routing
Non-Point-Related Events
Report
Description
Report
Routing
Report
Priority
System Test TESTS 4
System Test Restore TESTS 4
Silence TESTS 4
Fire Drill TESTS 4
Open Reset ALM RSTR, RST 4
Low Battery* TBL, TBL RSTR 3
Low Battery Restore* TBL, TBL RSTR 3
AC Fail* TBL, TBL RSTR 3
AC Fail Restore* TBL, TBL RSTR 3
Auto Test TESTS 4
Off Normal at Test TESTS 4
Phone 1 Trouble* TBL, TBL RSTR 3
Phone 2 Trouble* TBL, TBL RSTR 3
Phone 1 Restore* TBL, TBL RSTR 3
Phone 2 Restore* TBL, TBL RSTR 3
Manual Test* * TESTS 4
Data Lost TBL, TBL RSTR 6
EEPROM Failure* TBL, TBL RSTR 3
System Reset, Reboot TBL,TBL RSTR 3
Equipment Fail* TBL, TBL RSTR 3
Equipment Restore* TBL, TBL RSTR 3
Network Failure* TBL, TBL RSTR 3
Sensor Bus Failure* TBL, TBL RSTR 3
Trouble Input* TBL, TBL RSTR 3
Trouble Input Restore* TBL, TBL RSTR 3
System Trouble
Keypad*
TBL, TBL RSTR 3
System Restore
Keypad*
TBL, TBL RSTR 3
System Trouble Comm
Fault*
TBL, TBL RSTR 3
System Restore
Comm Fault*
TBL, TBL RSTR 3
System Trouble
Programming*
TBL, TBL RSTR 3
System Restore
Programming*
TBL, TBL RSTR 3
Comm Fail TBL 3
Comm Restore TBL RSTR 3
* Event is limited to a total of 100 reports sent in a 24-h
period. If this limit is exceeded, the100
th
event is replaced
with a Data Lost Report.
** Event resets the count of limited reports and can send 100
additional reports.
