EN | 37FPT-DACT | Operation & Installation Guide |
1/05 | F01U002505B
5.0 Programming
5.4.4 PROG RELAY
RELAY (______)
1: RELEAS ON TRBL
2: ACTIV GND STRT
The FPT-DACT contains a general system trouble relay
designed for fail-safe operation.
To access PROG RELAY:
1. At the Programming Menu, press [4] to select
4: PROG RELAY.
2. Press the number key that corresponds to your
selection. Refer to the following sections for trouble
relay programming information.
The relay can only be programmed for
RELEAS ON TRBL or ACTIV GND STRT.
It cannot perform both functions
simultaneously.
1: RELEAS ON TRBL
To access RELEAS ON TRBL, select [0]: PROGRAM
--->[4]: PROG RELAY--->[1]: RELEAS ON TRBL.
This option holds the on-board trouble relay normally
energized and releases it to indicate a trouble condition.
To set the system to hold and release a trouble relay:
1. At the Prog Relay Submenu, press [1] to select
RELEAS ON TRBL. The current setting appears in
parentheses.
2. Press [# Command] to verify your selection.
3. Press [* Clear] to return to the Programming Menu.
2: ACTIV GND STRT
To access ACTIV GND STRT, select [0]: PROGRAM
--->[4]: PROG RELAY--->[2]: ACTIV GND STRT.
This option allows the FPT-DACT to use the on-board
trouble relay for ground start operation.
To set the system to use the on-board trouble relay for
ground start operation:
1. At the Prog Relay Submenu, press [2] to select
2: ACTIV GND STRT. The current setting appears
in parentheses.
2. Press [# Command] to verify your selection.
3. Press [* Clear] to return to the Programming Menu.
5.4.5 PROG ACC’NTS
PROG ACC’NTS
1: ACCOUNT NUMS
2: PHONE NUMS
3: PHONE CONTROL
4: RPT STEERING
5: LINE CONTROL
6: ACK WAIT TIME
The PROG ACC’NTS feature allows you to program
parameters for event reporting.
To program parameters for event reporting:
1. At the Programming Menu, press [5] to select
5: PROG ACC’NTS.
2. Press the number key that corresponds to your
selection. Refer to the following sections for account
programming information.
1: ACCOUNT NUMS
To access ACCOUNT NUMS, select [0]: PROGRAM
--->[5]: PROG ACC’NTS--->[1]: ACCOUNT NUMS.
The account numbers identify the FPT-DACT when it
reports to the central station.
To use account numbers to identify the FPT-DACT
when reporting the central station:
1. At the PROG ACC’NTS Submenu, press [1] to
select 1: ACCOUNT NUMS. The window shows:
ACCOUNT NUMS
1: NUMBER 1
2: NUMBER 2
2. Press the number that corresponds with the account
number you want to set. The window shows:
ACCOUNT #1: 0000
NEW NUMBER: 0000
3. The existing number appears on the top line. Access
hexadecimal digits A through F by pressing [Test].
Press [1] for A, [2] for B, [3] for C, [4] for D, [5] for
E, and [6] for F.
4. Enter the new number on the second line and press
[#] to verify your entry.
5. Press [* Clear] to return to the Prog Acc’nts
Submenu.
6. Program Account Number 2 using the same
procedure.
0000 is not a valid account number. At least
one of the digits must be non-zero.
2: PHONE NUMS
To access PHONE NUMS, select [0]: PROGRAM
--->[5]: PROG ACC’NTS--->[2]: PHONE NUMS. The
system can be programmed with two reporting
telephone numbers. Use Phone Number 1 with Account
Number 1 and Phone Number 2 with Account Number
2. Remote programming occurs on Phone Line 1 using
Phone Number 3.
• PHONE #1 is Phone Number 1.
• PHONE #2 is Phone Number 2.
• PHONE #3 is Phone Number 3. This telephone
number is not available at this time. It is reserved for
future use.
