1/05 | F01U002505B
EN | 38FPT-DACT | Operation & Installation Guide |
5.0 Programming
To comply with UL and NFPA standards, use
both telephone numbers.
To program the system with telephone numbers:
1. At the Prog Acc’nts Submenu, press [2] to select
PHONE NUMS. The window shows:
PHONE NUMS
1- PHONE #1
2- PHONE #2
3- PHONE #3
2. Press the number key that corresponds with the
telephone number you want to configure. In this
example, [1] was pressed to select 1: PHONE #1.
The window shows:
PHN NMBR 1: ????
????????????????
3. Enter the telephone number. Press [Drill] or
[Disable] to move between the digits.
4. Press [# Command] when the entry is complete.
Then, press [* Clear] to return to the Prog Acc’nts
Submenu.
Before exiting the Phone Numbers
Programming Submenu, refer to the
following information on special control
codes for telephone numbers.
You can include several special control codes in the
telephone number by pressing [Test]. These telephone
control codes are:
PHONE CONTROL CODE
1: * CODE
2: # CODE
3: /3 SEC DELAY
• * CODE: Press [Test] and then [1] for Touch Tone “*”
action.
• # CODE: Press [Test] and then [2] for Touch Tone
“#” action.
• /3 SEC DELAY: Press [Test] and then [3] for a
3-sec delay.
3: PHONE CONTROL
To access PHONE CONTROL, select [0]: PROGRAM
--->[5]: PROG ACC’NTS--->[3]: PHONE CONTROL.
There are features associated with each telephone
number. The following information describes these
features.
To set telephone control:
1. At the Prog Acc’nts Submenu, press [3] to select
3: PHONE CONTROL. The window shows:
PHONE CONTROL
1: PHONE 1 FORMAT
2: PHONE 2 FORMAT
3: PHONE 1 TONE
4: PHONE 2 TONE
5: PHONE 1 TEXT
6: PHONE 2 TEXT
3: PHONE 1 TONE and 4: PHONE 2
TONE options are in 4/2 format only. Refer
to Step 4 for tone settings.
2. Press the number key (1 or 2 for Phone Format) that
corresponds to the telephone you want to configure.
In this example, PHONE #1 is selected. The
window shows:
PHONE FORMAT (__)
1: 4/2 REPORT
2: SIA 110, RPRT
3: CONTACT ID
4: SIA 300, RPRT
5: MODEM III
3. Press the number key that corresponds to your
selection. The current setting appears in parentheses
on the first line. Press [# Command] to verify your
selection. Then press [* Clear] to return to the
Phone Control Submenu.
4. Use the Phone 1 Format instructions when setting
the Phone 2 Format.
5. Configure the tone setting by pressing [3] at the
Phone Control Submenu. In this example, PHONE
#1 is selected. The window shows:
TONE (_____)
1: 19D, 14A, 10PS
2: 18D, 23A, 10PS
3: 19D, 14A, 20PS
4: 18D, 23A, 20PS
5: 19D, 14A, 40PS
6: 18D, 23A, 40PS
The “D” in “XXD” is the data frequency. “A”
in “XXA” is the acknowledge tone. “PS” in
“XXPS” is the pulse per second.
6. Press the number key that corresponds to your
selection. The current setting appears in parentheses
on the first line.
