Bosch FPT-DACT - Table 12: Equipment Fail Conditions

EN | 51FPT-DACT | Operation & Installation Guide |
1/05 | F01U002505B
Appendix C
Note 1: Some codes are used for more than one event type.
Note 2: For SIA and Modem III
a2
, no area is reported.
Note 3: For contact ID, the area is 0.
Note 4: The point is reported as Points 1 to 5, corresponding to the five inputs.
Note 5: ppp and pppp are point numbers. The SIA can be one to four digits.
Note 6: a, aa, and aaaa are numbers. The SIA can be one to four digits.
Note 7: iii and iiii are used IDs. The SIA can be one to four digits.
Note 8: nn, nnn, and nnnn are condition parameters. The SIA can be one to four digits.
Note 9: For the 4/2 code, P is a programmable digit for each input point.
On a FPT-DACT that is serially connected to an analog FACP, Table 11 on pageS 49 and 50 only applies if the
reported address (C for Contact ID, SDI for Modem IIIa
2
) is less then 100. If the address reported is greater than
100, the reported event is a Peripheral Fault.
Table 12 identifies the Equipment Fail conditions. The Equipment Fail appears as a System Trouble in Contact ID.
Table 12: Equipment Fail Conditions
Code Event Data in Address Field Generated By Description
2 Dialer Trouble
Input
Point Dialer A point configured for Fault on Open or Fault on
Short was tripped.
5 System Trouble
Keypad
N/A Dialer The programming keypad was connected to the
FPT-DACT.
6 Comm Fault N/A Dialer A Comm Fault occurred.
11 System Trouble
Programming
N/A Dialer Programming was entered on the D9068.
12 Network Failure Control panel address Control panel A control panel fail or restore occurred.
13 FACP
Programming
Control panel address Control panel The control panel was left in the Programming
Mode.
14 FACP Config
RPS Fail
Control panel address Control panel The RPS Config failed.
15 FACP Processor
Reset
Control panel address Control panel The processor reset.
16 FACP
Unresolved IRQ
Control panel address Control panel There is an unresolved interrupt request (IRQ).
17 FACP Ground
Fault
Control panel address Control panel There is a ground fault.
18 FACP Loop
Wiring Fault
Control panel address Control panel There is a fault in wiring loop.
19 FACP NAC A
Open
Control panel address Control panel The notification appliance circuit (NAC) A is open.
20 FACP NAC A
Short
Control panel address Control panel The NAC A is short.
21 FACP NAC B
Open
Control panel address Control panel The NAC B is open.
22 FACP NAC B
Short
Control panel address Control panel The NAC B is short.
