Bosch Rexroth MS2N User Manual

6.3 Connection water cooling
Any installation material, like tubes or mounting clamps are not in the scope of
delivery. Choose a supply hose with correct inner diameter.
Coolant connection
Fig. 6-8: Coolant connection MS2N07
Fig. 6-9: Coolant connection MS2N13-XXXXL-XXEXX
The allocation of intake (IN) and outtake (OUT) can be arbitrarily
done. It does not influence the power data of the motor in any way.
78/101
Assembly
MS2N Synchronous Servomotors
Bosch Rexroth AG R911347581_Edition 04
