Motor Connection, rotatable Total length [mm] S [mm]
MS2N03 03P L + 15 + S 6.9
MS2N04 04P L + 15 + S 3.3
MS2N05 05P L + 18 + S 9.2
MS2N06 06P L + 18 + S 9.2
MS2N07 07P L + 16 + S 10.4
MS2N10 10P L + 16 -
L Measure of length "Standard L" from specifications
Tab. 4-16: Total length of motor with sealing air connection
Damage due to ingress of dirt!
The compressed air gland is not closed upon delivery. Always operate motors
with compressed air connection with connected compressed air supply.
Further information chapter 6.4 "Sealing air connection " on page 82.
4.2.15 Noise emission
The typical sound pressure level Lp(A) is specified for the speed range 0 rpm up
to the rated speed, see chapter 4.2.1 "Basic data" on page 10. The installation
situation affects the noise emission.
MS2N Synchronous Servomotors 37/101
About this product
R911347581_Edition 04 Bosch Rexroth AG
