Storage time/months
Measures for commissioning
> 1 > 12 > 60
● ●
Measure insulation resistance. Dry the winding at a value of < 1kOhm per volt
rated voltage.
● Replace bearings
● Replace encoders
Tab. 5-8: Measures before commissioning motors that have been stored over a prolonged
period of time
5.6 Shock load during transport und storage
MS2N motors comply with the transport condition requirements of class 2M4
(shock during transport) acc. to EN 60721-3-2 compare with chapter 5.4 "Trans-
port" on page 44. Function-impairing effects are avoided as long as the specified
limits are complied with.
Frame size
Maximum allowed shock load (11 ms)
Axial Radial
MS2N03, -04, -05
100 m/s²
1000 m/s²
MS2N06 500 m/s²
MS2N07 300 m/s²
MS2N10, 13 200 m/s²
Tab. 5-9: Permissible shock load for MS2N motors
The specified limit values do not apply to half-sine-shaped single shock load acc.
to EN 60068-2-27.
The specifications do not apply to
motor operation. Applications
with continuous shock load make a case-by-case review necessary.
MS2N Synchronous Servomotors 47/101
Operating conditions and handling
R911347581_Edition 04 Bosch Rexroth AG
