Type Holding
torque
Dynamic
braking
torque
Rated
voltage
1)
Rated
current
Maxi-
mum
connec-
tion time
Maxi-
mum dis-
connec-
tion time
Moment of
inertia of the
holding
brake
Maxi-
mum
switched
energy
M
4
Nm
M
1
Nm
U
N
V
I
N
A
t
1
ms
t
2
ms
J
br
kg*m
2
W
max
J
MS2N06-C____-____1-_____-
__
10.00 4.5 24 0.73 30 80 0.0001070 400
MS2N06-D____-____2-_____-
__
15.00 11 24 0.75 50 135 0.0001400 888
MS2N06-E____-____2-_____-
__
15.00 11 24 0.75 50 135 0.0001400 888
MS2N07-C____-____1-_____-
__
20.00 12.5 24 0.78 40 100 0.0002550 340
MS2N07-D____-____2-_____-
__
36.00 16.5 24 0.94 60 200 0.0004100 850
MS2N07-E____-____2-_____-
__
36.00 16.5 24 0.94 60 200 0.0004100 850
MS2N10-B____-____1-_____-
__
33.00 16.5 24 0.94 60 200 0.0004100 850
MS2N10-C____-____2-_____-
__
53.00 23 24 1.00 70 220 0.0014700 850
MS2N10-D____-____2-_____-
__
53.00 23 24 1.00 70 220 0.0014700 850
MS2N10-E____-____3-_____-
__
90.00 33 24 1.50 65 250 0.0027000 1470
MS2N10-F____-____3-_____-
__
90.00 33 24 1.50 65 250 0.0027000 1470
1) Tolerance ± 10%
Tab. 4-10: Holding brakes - Technical data
t
1
Connection time (close)
t
2
Disconnection time (open)
Fig. 4-7: Switching times of static hold mode
28/101
About this product
MS2N Synchronous Servomotors
Bosch Rexroth AG R911347581_Edition 04
