Motor Opening for cable insert "X"
MS2N10-C0BHA-xxTxx-xxxxx-xx
MS2N10-C0BHB-xxTxx-xxxxx-xx
MS2N10-C0BNA-xxTxx-xxxxx-xx
MS2N10-C0BNB-xxTxx-xxxxx-xx
MS2N10-C0BNL-xxTxx-xxxxx-xx
2x M32
MS2N10-D0BHA-xxTxx-xxxxx-xx
MS2N10-D0BHB-xxTxx-xxxxx-xx
MS2N10-D0BHL-xxTxx-xxxxx-xx
MS2N10-D0BNA-xxTxx-xxxxx-xx
MS2N10-D0BNB-xxTxx-xxxxx-xx
MS2N10-D0BNL-xxTxx-xxxxx-xx
MS2N10-E0BHA-xxTxx-xxxxx-xx
MS2N10-E0BHB-xxTxx-xxxxx-xx
MS2N10-E0BHL-xxTxx-xxxxx-xx
MS2N10-E0BNA-xxTxx-xxxxx-xx
MS2N10-E0BNB-xxTxx-xxxxx-xx
MS2N10-F0BDA-xxTxx-xxxxx-xx
MS2N10-F0BDB-xxTxx-xxxxx-xx
MS2N10-F0BHA-xxTxx-xxxxx-xx
MS2N10-F0BHB-xxTxx-xxxxx-xx
2x M40
Tab. 6-20: MS2N terminal box "T" cable entry
