Motor Opening for cable insert "X" Opening for cable insert "Y"
MS2N10-E0BNL-xxCxx-xxxxx-xx
MS2N10-F0BHL-xxCxx-xxxxx-xx
3x M50 1x M20
MS2N13-B1BHC-xxCxx-xxxxx-xx
MS2N13-C1BHC-xxCxx-xxxxx-xx
MS2N13-C1BHL-xxCxx-xxxxx-xx
4x M50 1x M20
Tab. 6-24: MS2N terminal boxes "C" cable entry
MS2N Synchronous Servomotors 67/101
Assembly
R911347581_Edition 04 Bosch Rexroth AG
