Inputs > Input Testing >
tst-zn
Walk Test A Single Zone
MENU 3-9-1
This menu allows you to select a single zone to be tested
via walk test.
1. Enter your Master PIN + [MENU].
2. Enter [3] + [9] + [1] + [OK].
The keypad will display the Zn = prompt.
Zn=
3. Enter the zone number you want to test, then press
[OK].
test
2
4. Fault and restore the zone to be tested.
If the zone test was sucessful, the keypad will display
PASS.
The system will also chirp the sirens for 1 second if
the zone test was sucsessful making it easier for one
person to do the test.
PASS
5. Press [OK] to exit when nished.
Output Options
The control panel can have up to 8 outputs. Four outputs
are available as standard with an additional four available
when the optional output expander is tted.
Outputs are used to operate sirens, strobe lights etc and
can also be used to control automatic doors and gates.
Your installer will advise you on the exact makeup and
conguration of your system.
Outputs > Commands >
StAtus
Output Status
MENU 4-0-0
This menu allows you to view the the current status of each
output.
1. Enter your Master PIN + [MENU].
2. Enter [4] + [0] + [0] + [OK].
The keypad will ash the Op = prompt.
OP=
3. Enter the output number you want to view, then
press [OK].
The keypad will now display the status of the selected
output.
There are 4 posible states.
iS OFF - output is OFF,
iS On - Output is ON and
cOnLSt - Connection Trouble.
OvLOAd - Connection Overload.
If connection trouble or connection overload is shown
there may be a problem with an output device on the
system. In this case you should contact your installer
for further information.
The keypad will display the following when output 3
is OFF.
is Off
The keypad will display the following when output 2
is ON.
is On
The keypad will display the following when output 3
has a connection trouble (output device is missing).
cOnLSt
The keypad will display the following when output 3
has an overload condition.
OvLOAd
4. Press [OK] to exit.
