Bosch Solution 16i User Guide

Solution 16 i
22
Bosch Security Systems 6/09 BLCC500U FTR1.03
User Guide
Outputs > Commands >
On-Off
Turn Output On/Off
MENU 4-0-1
This menu allows you to manually control the system
outputs that have been programmed by your installer.
Outputs can be programmed to control sirens, strobe
lights, outside lighting, pool pumps, watering systems etc.
1. Enter your Master PIN + [MENU].
2. Enter [4] + [0] + [1] + [OK].
The keypad will ash the Op= prompt. Any output(s)
which are currently on will also be displayed.
Op=
1 3
If your system is congured for multiple areas the area
Icon for the current area will also be displayed.
3. Enter the output number + [OK] to toggle the output
on or o.
Repeat step 3 for any additional outputs that you need
to control.
4. Press [OK] to exit.
Outputs > Properties >
OPnAME
Output Name
MENU 4-1-0
This menu allows the master user to program name of each
Output (Up to 16 characters). Use the [←] and [→] keys to
move the cursor position left and right to view the zone
name.
The text programming procedure is very similar to that of
most mobile phones. Refer the Programming Text section
on page 10 for more details.
Output names are stored with associated events in the
system’s history log. This enables accurate auditing of
events at a later time if required. Names are also used
when reporting alarms and turning an area on and o in
SMS and other text based reporting formats.
Each output has a default name which can be changed if
desired. The default names are as follows.
DEFAULT OUTPUT NAMES
Output Number Default Name
1 E
ternAl Siren
2 strObe
3
smOke sensOr
4 InternAl Siren
5 Output 5 NAme
6 Output 6 NAme
7 Output 7 NAme
8 Output 8 NAme
Table 11: Default Output Names
Outputs 5 to 8 are available when an optional output
expander is tted. Discuss this feature with your installer.
1. Enter your Master PIN + [MENU].
2. Enter [4] + [1] + [0] + [OK].
The keypad will ash the Op = prompt.
Op=
3. Enter the output number (1 to 8) you want to
program, then press [OK].
StrObe
4. Use keys [0] to [9], [←] and [→] keys to change the
Output Name text as required.
At any time you can use the [↑] and [↓] keys to scroll
through the complete list of available characters. To
clear all text from the cursor position to the right, press
the [OFF] key.
5. When the Output Name is complete, press [OK] to
save and exit, or press [MENU] to exit without saving.
Outputs > Output Testing >
tStSir
External Siren Test
MENU 4-9-0
This menu allows you to test the external sirens
which have been connected to the system.
The test will last for 5 seconds.
1. Enter your Master PIN + [MENU].
2. Enter [4] + [9] + [0] + [OK].
If your system has been congured to have more than
one area, the keypad will display the A = prompt.
A=
3. Enter the Area number in which to test the external
sirens in and then press [OK].
BELL

ALARM
The keypad will display ‘Siren’ and the alarm icon during
the audible 3 second siren test.
