Solution 16 i
4
Bosch Security Systems 6/09 BLCC500U FTR1.03
User Guide
Programming Menu
The Solution 16i control panel includes an extensive range of features and options which enable your installer to taylor
the system to suit your exact security requirements. The panel includes a number of user options which can be changed
or modied by you if and when required.
This guide explains each of these in detail and includes examples on how to use each particular feature. The examples
show how to perform each function using the menu or loaction numbers in the system. It is also possible to access many
of the options using the simple text menus shown in the table below.
To access the text menus, enter your PIN + [MENU] key. Once the Access menu appears, use the [↑], [], [←] and [→]
naviagation keys to move around the menus and options. To drill down into an option press the [OK] key and follow the
prompts. To move back one level, press the [MENU] key. When programming locations, pressing the [OK] key will save
your changes and pressing the [MENU] key will abort any changes you have made in that location. To exit programming
at any time press and hold the [MENU] key for 2 seconds.
If you are unclear on any items in this guide, please contact your installer as they are best equiped to answer questions
releating to your particular installation.
Menu Nº Display Access Menu Menu Nº Display Comms Menu
1-1-0
ch-Pin Change Own PIN
5-1-5
set-ph Domestic Phone Nº
1-1-1
ch-Oth Change Other PIN
5-0-2
cfOnOf Call Forward On/O
1-4-1
UrAreA Area Assignment
5-1-6
cfOnPh Call Forward On Ph Nº
1-1-2
AddPin Add PIN
5-1-7
cfOfph Call Forward O Ph Nº
1-2-0
AddPrO Add Token
5-0-1
cAlAns Call / Answer RAS
1-3-0
AddFOb Add Keyfob
5-0-5
dircOn Direct Connect
1-1-3
delpin Delete PIN
5-0-8
cusreg Customer Registration
1-2-1
delprO Delete Token
5-9-0
tst-dl Send Test Report
1-3-1
delfOb Delete Keyfob
5-3-8
ur-rAs User RAS Security PIN
1-0-0
del-ur Erase User
5-0-6
VOice Voice Module Setup
1-4-4
tmrGrp Timer Group
5-5-8
EmAil Email Address
1-4-5
ur-Acc Access Assignment
5-5-9
E-Opts Email Options
1-2-2
id PrO Token Status
1-4-0
UrnAme User Name Devices Menu
6-1-0
cp-vOl Volume
Areas Menu
6-1-1
cp-cOn Contrast
2-0-5
chOnOf Chime On/O
6-1-2
cp-bl Backlight
2-0-6
ch typ Chime Mode
7-7-3
cP-deg Hi/Lo Temperature
2-1-0
A-NAme Area Name
6-0-0
LAN-St LAN Status
Inputs Menu System Menu
3-0-0
stAtus Zone Status
7-0-0
StAtus Panel Status
3-0-2
bypAss Bypass Zones
7-1-0
cLOck Set Date & Time
3-0-5
Fire-r Smoke Sensor Reset
7-1-1
St-On Summer Time On
3-0-3
ch-Zn Set Chime Zones
7-1-2
St-Off Summer Time O
3-0-4
pt2-zn Set Part 2 Zones
7-0-2
HislOg View History Log
3-9-1
tst-zn Walk Test A Zone
5-0-4
SndLOg Email History Log
3-9-0
tstzns Walk Test All Zones
7-0-1
trbl System Trouble
3-1-0
znnAme Zone Name
7-9-1
tst-bA Battery Test
7-5-1
Shtime Schedule Time
Outputs Menu
7-5-2
Sh DAy Schedule Day
4-0-0
stAtus Output Status
7-5-0
ShNAme Schedule Name
4-0-1
On-Off Turn Output On/O
7-6-0
HonAme Holiday Name
4-9-0
tstsir External Siren Test
7-6-1
Hotime Holiday Dates
4-9-1
tstInt Internal Siren Test
7-7-7
Site Site Name
4-9-2
tststr Strobe Test AboVt Panel Information
4-1-0
OPnAme Output Name
Table 1: Programming Menu Structure
