Solution 16 i User Guide
Trouble Event Number
Trouble Event
Description
Device or
Module Number
Trouble Text
Description #1
Trouble Text
Description #2
F48-Panel # Panel Phone Line Fail P001 rEPOrt fAil
F49-Panel # Panel Service Mode P001 InStAl OnSite
F50-Panel # Panel Eprom Fail P001 dAtA ErrOr
F51-Panel # Panel Comm+ Overload P001 Out 12 LEvEl
F52-Panel # Panel LAN Overload P001 LAn 12 LEvEl
F53-Panel # Panel ACC Overload P001 Acc 12 LEvEl
F54-Panel # Panel - TCP IP Comm Fail P001 IP POl FAil 1
F55-Panel # Panel - TCP IP Comm Fail P001 IP POl FAil 2
F60-RTC # RTC Module Missing CL001 LOst
F61-RTC # RTC Module Tamper CL001 cASE OPEn
F62-RTC # RTC Module Low Battery CL001 bAttrY LEvEl
F63-RTC # RTC Module Missing Battery CL001 NO bAttrY
F64-RTC # RTC Clock Error rtC001 clOc Error
F70-Receiver # RF Receiver Missing rF001 Lost
F71-Receiver # RF Receiver Tamper rF001 cASE OPEn
F72-Receiver # RF Receiver Jam rF001 SiGnAL HiGH
F80-Power Supply # P/S Module Missing PS001 LOSt
F81-Power Supply # P/S Module Tamper PS001 cASE OPEn
F82-Power Supply # P/S Module AC Fail PS001 NO AC
F83-Power Supply # P/S Module Low Battery PS001 bAttrY LEvEl
F84-Power Supply # P/S Module Battery Missing PS001 NO bAttrY
F85-Power Supply # P/S Module Output Overload PS001 Out 12 ShOrt
F88-Output Module # Output Module Expander Missing OE001 LOSt
F89-Output Module # Output Module Expander Tamper OE001 cASE OPEn
F90-Keypad # Keypad Missing CP00x LOst
F91-Keypad # Keypad Tamper CP00x cASE OPEn
F91-Reader # LAN Reader Tamper LP00x cASE OPEn
F92-Keypad # Keypad High Temperature CP00x tOO HOt
F93-Keypad # Keypad Low Temperature CP00x tOO COld
F100-Module # Ethernet Module Missing Et001 LOst
F101-Module # Ethernet Module IP Changed Et001 IP chAnGE
F102-Module # Ehternet Module No Connection Et001 nO cAbLE
F103-Module # Ethernet Module IP Lockout Et001 LOch Out
F104-Module # Ethernet Module IP Conict Et001 IP uSEd
Table 24: System Trouble / Fault Descriptions
