10 Technical specifications
900-351_IFU_V2.0.0_20221-S0-20150520-EN Operating Manual ARC 350 101
Monopolar Coagulation – Argon flex. pulse
Measurement at ohmic resistances
 Diagram of power output P [W] as a
function of the load resistance R [] for
the setting "Monopolar Coagulation
Argon flex. pulse"
= 40 W
Measurement at ohmic resistances
 Diagram of power output P [W] as a
function of the load resistance R [] for
the setting "Monopolar Coagulation
Argon flex. pulse"
= 80 W
 Diagram of power output P [W] as a
function of the setting "Monopolar
Coagulation Argon flex. pulse"
Rated load resistance = 500 
Effect
U (Vp)
1
4400
2
4400
3
4400
 Table HF output voltage U [Vp] as a
function of the setting "Monopolar
Coagulation Argon flex. pulse" (idle
mode)
The puls frequency changes with the effect setting. The higher the effect
level, the faster the pulse sequence.
Effect 1: 1 Hz, effect 2: 5 Hz, effect 3: 10 Hz
The mode "Argon flexible" is paused due to the pulse sequence.
